Automatic Pin Insert Assembly Machine

1, The working principle

The main working principle of the automatic pin insertion machine is to automatically operate through the manipulator or mechanical arm, pair the plug and socket, and complete the automatic insertion of the connector. It can realize the combination of multiple processes in the working process, including the feeding, calibration, pairing, plugging and so on.

Specifically, the work flow of the automatic pin insertion machine is roughly as follows:

1.Feeding system: Connector components such as plugs and sockets are supplied to the robot gripper by means of a vibrating disc or feeder.

2.Manipulator/arm: Automatic pairing and plugging of connector components.

3.Control system: Control the action and position of the manipulator/robot arm to ensure the correct insertion of each component.

2, Application field

Automatic pin insertion machines have a wide range of applications in a number of fields, including but not limited to:

Smart phones: In the production line of smart phones, the automatic pin insertion machine can complete the assembly of high-density circuit boards with higher efficiency, greatly improving the production efficiency.

Home appliances: Automatic pin machine in the manufacturing process of home appliances, you can efficiently assemble a variety of electronic connectors, improve production efficiency and quality.

Automotive electronics: In the field of automotive electronics, automatic pin insertion machines are used to assemble electronic devices and connectors inside automobiles to ensure the normal operation of automotive electrical systems.

3, Market status and development trend

1.Market size: In 2024, the global automatic pin machine market size is about 945 million US dollars, and it is expected that the compound annual growth rate of 4.9% in the next six years will reach 1308 million US dollars by 2031.

2.Market competition: Automatic pin machine market competition is increasingly fierce, the core manufacturers include Universal Instruments, Panasonic, Juki, etc., these manufacturers occupy more than 60% of the global share.

3.Technological innovation: With the trend of intelligent manufacturing becoming more and more obvious, the introduction of various artificial intelligence technologies has made the performance of automatic pin insertion machine continue to improve, and the production efficiency continues to improve.

4, Advantages and characteristics

1.Improve production efficiency: Automatic pin insertion machine can greatly improve production efficiency, reduce manual operation time, and reduce production costs.

2.Ensure product quality: With the help of high-precision needle insertion technology, the automatic needle insertion machine can ensure product quality and reduce the workload of subsequent quality inspection.

3.High flexibility: The automatic pin insertion machine can realize the adjustment of process characteristics through software control to meet the needs of different types of insertion.

In summary, as an efficient and accurate automatic assembly equipment, automatic pin insertion machine has a wide range of applications in many fields. With the continuous development of intelligent manufacturing, automatic pin insertion machines will continue to play an important role in providing strong support for the production of various industries.
